Quick Coupler UDC plug series
Model :
UDC-P
ㆍSHPI Universal quick coupler is extensively used in European and American market.
ㆍPush-in one touch type inserting socket method.
| Model Number | Application |
L
(mm)
|
T (Hex)
(mm)
|
A
(mm)
|
ØB
(mm)
|
| UDC20P | 5mm*8mm | 58.8 | 14 | 13 | 4 |
| UDC30P | 6.5mm*10mm | 64 | 5/8 | 18.5 | 5 |
| UDC40P | 8mm*12mm | 65.5 | 19 | 20 | 6.5 |
ㆍPlug for MP, AP and OP series for American/ European market
ㆍBrass material
ㆍMax. working pressure: 300 PSI
ㆍPneumatic tools
ㆍAir piping
ㆍAir pressure equipment
