• DOT Push-in Fitting Bulkhead Union 82 Series

DOT Push-in Fitting Bulkhead Union 82 Series

Model : DOT-82

ㆍWorking pressure: up to 150 psi
ㆍWorking temperature range:-40°F to +200°F
ㆍThreads: NPTF Standard. For other threads standards consult factory
Model Number Tube O.D
35-8204 1/4"
35-8206 3/8"
35-8208 1/2"
ㆍSHPI's D.O.T. Air brake fittings manufacturing meets D.O.T. FMVSS 571.106
ㆍAir brake specifications and SAE J2494 standards.
ㆍMachined from C3600/C3700 brass alloy
ㆍPre-applied thread sealant on all male pipe threads
ㆍOne-touch connection reduces installation time and cost
ㆍVarious shapes and configurations to meet vehicle applications and make installation easier
ㆍRecommended Tubing: SAE J844 nonmetallic air brake systems
