Hypretex High Pressure Jetting/Lateral Line Hose HJL-40
Model :
HJL-40
ㆍInner Tube: Polyolefin tube
ㆍReinforcement: One or two braided of synthetic fiber
ㆍCover: Abrasion resistant green Polyurethane color
ㆍTemperature Range: -40°C ~60°C (-40°F ~140°F)
ㆍReinforcement: One or two braided of synthetic fiber
ㆍCover: Abrasion resistant green Polyurethane color
ㆍTemperature Range: -40°C ~60°C (-40°F ~140°F)
| Part Number | Size Code |
Tube I.D
(inch)
|
Tube O.D
(inch)
|
Max. Working Pressure
(psi)
|
Min. Bursting Pressure
(psi)
|
Min. Bend Radius
(inch)
|
Weight
(lbs/ft)
|
| HJL40-03 | 03 | 3/16 | 0.41 | 4000 | 12000 | 1.7 | 0.065 |
| HJL40-04 | 04 | 1/4 | 0.485 | 4000 | 12000 | 2 | 0.075 |
| HJL40-06 | 06 | 3/8 | 0.72 | 4000 | 12000 | 2.25 | 0.133 |
| HJL40-08 | 08 | 1/2 | 0.84 | 4000 | 12000 | 3 | 0.16 |
ㆍMaterials: Constructed to provide rugged and reliable service under the most severe and demanding conditions
ㆍPolyolefin Tube: Provides maximum resistance to hydrolysis
ㆍHigh Tensile Synthetic Fiber Braids: Contributes to low volumetric expansion & eliminates loss of strength from moisture absorption
ㆍAbrasion Resistant Ether base Polyurethane cover provides exceptional cut, abrasion and fungus resistance
ㆍSlippery hose cover allows hose to maneuver around and through difficult sewer bends
ㆍPolyolefin Tube: Provides maximum resistance to hydrolysis
ㆍHigh Tensile Synthetic Fiber Braids: Contributes to low volumetric expansion & eliminates loss of strength from moisture absorption
ㆍAbrasion Resistant Ether base Polyurethane cover provides exceptional cut, abrasion and fungus resistance
ㆍSlippery hose cover allows hose to maneuver around and through difficult sewer bends
ㆍUsed on high pressure sewer cleaning equipment
ㆍFor commercial, industrial and residential
ㆍSlick cover affords an easier handling hose to get the job done
ㆍFor commercial, industrial and residential
ㆍSlick cover affords an easier handling hose to get the job done
