Hypretex Paint Spray Hose series Paint R8
Model :
PR8
ㆍInner Tube: Polyamide
ㆍReinforcement: One or two braided of aramid fiber
ㆍCover: Red high abrasion resistant polyurethane pinpricked cover
ㆍTemperature Range: -40°C ~93°C (-40°F ~200°F) limited to 70°C for air and water based fluids
| Part Number |
Tube I.D
(inch)
|
Tube O.D
(inch)
|
Max. Working Pressure
(psi)
|
Min. Bursting Pressure
(psi)
|
Min. Bend Radius
(inch)
|
Weight
(lbs/ft)
|
| PR8-316 | 3/16 | 0.374 | 5000 | 20000 | 1.18 | 0.037 |
| PR8-14 | 1/4 | 0.476 | 3000 | 12000 | 1.97 | 0.06 |
| PR8-38 | 3/8 | 0.614 | 4000 | 16000 | 2.36 | 0.087 |
| PR8-12 | 1/2 | 0.748 | 3500 | 14000 | 3.15 | 0.117 |
ㆍHigh pressure flexible hose
ㆍRed pinpricked cover
ㆍLight weight and high flexibility
ㆍConductive inner layer
ㆍFor use in Airless/Wireless paint spray systems
ㆍApplications requiring high chemical resistance to solvents and aggressive fluids
