Hypretex Paint Spray Hose series Paint R7
Model :
PR7
ㆍInner Tube: Polyamide
ㆍReinforcement: One or two braided of aramid fiber
ㆍCover: Blue high abrasion resistant polyurethane pinpricked cover
ㆍTemperature Range: -40°C ~93°C (-40°F ~200°F) limited to 70°C for air and water based fluids
| Part Number |
Tube I.D
(inch)
|
Tube O.D
(inch)
|
Max. Working Pressure
(psi)
|
Min. Bursting Pressure
(psi)
|
Min. Bend Radius
(inch)
|
Weight
(lbs/ft)
|
| PR7-316 | 3/16 | 0.39 | 3000 | 12000 | 0.98 | 0.04 |
| PR7-14 | 1/4 | 0.484 | 3000 | 12000 | 1.38 | 0.064 |
| PR7-38 | 3/8 | 0.63 | 2300 | 9200 | 2.17 | 0.094 |
| PR7-12 | 1/2 | 0.799 | 2000 | 8000 | 2.95 | 0.141 |
ㆍMedium pressure flexible hose
ㆍBlue pinpricked cover
ㆍLight weight and high flexibility
ㆍFor use in Airless/Wireless paint spray systems
ㆍApplications requiring high chemical resistance to solvents and aggressive fluids
ㆍProviding electrical conductivity
