Quick Plug OP female series
Model :
OP-F
ㆍSHPI European System quick coupler is extensively used in the European market and other areas.
(such as Russia, Eastern European countries and certain regions in the U.S.A.)
ㆍPush-in one touch type inserting method.
(such as Russia, Eastern European countries and certain regions in the U.S.A.)
ㆍPush-in one touch type inserting method.
| Model Number | Application |
L
(mm)
|
H (Hex)
(mm)
|
A
(mm)
|
T
(Thread)
|
| OP20F | 1/4" | 33.5 | 5/8 | 11 | 1/4 PT |
| OP30F | 3/8" | 37 | 19 | 12.5 | 3/8 PT |
| OP40F | 1/2" | 41 | 24 | 16 | 1/2 PT |
ㆍBrass material
ㆍMax. working pressure: 300 PSI
ㆍMax. working pressure: 300 PSI
ㆍPneumatic tools
ㆍAir piping
ㆍAir pressure equipment
ㆍAir piping
ㆍAir pressure equipment
