Quick Coupler NSC male swivel series
Model :
NSC-MS
ㆍFor Japanese market, Asia, Russia, India, Brazil, New Zealand and Australia all use considerable quantities of this system.
ㆍA.K.A. :
Air Quick Coupler / Quick Disconnect Coupling
Quick Disconnector / Quick Connect
Air Quick Coupling / Air Connectors & fitting
Quick coupling / Pneumatic couplings
| Model Number | Application |
L
(mm)
|
H (Hex)
(mm)
|
HS
(mm)
|
T
(Thread)
|
ØB
(mm)
|
| NSC20MS | 1/4" | 66.8 | 19 | 13 | 1/4 PT | 7 |
| NSC30MS | 3/8" | 67.8 | 19 | 14 | 3/8 PT | 8 |
| NSC40MS | 1/2" | 69.8 | 21 | 16 | 1/2 PT | 12 |
ㆍOne touch type
ㆍLock mechanism
ㆍSteel material with plated finish
ㆍMax. working pressure: 300 PSI
ㆍPneumatic tools
ㆍAir hose/ tube
ㆍAir pressure equipment
