• One Touch Fitting PLF extended female elbow

One Touch Fitting PLF extended female elbow

Model : PLF-g

ㆍWorking Pressure Range / 0~150PSI /0~9.9Kgf/cm2(0~990KPa)
ㆍNegative Pressure /-29.5in Hg/-750mmHg(-750Torr)
ㆍWorking Temperature Range / 32°F~140°F / 0~60°C

Model Number ØD
T
(Thread)
E L A
H (Hex)
(mm)
Q'ty per bag Q'ty per box
PLF 04-G01 4 G 1/8 23.5 28.5 8 14 10 50
PLF 04-G02 4 G 1/4 23.5 31 11 17 10 50
PLF 04-G03 4 G 3/8 23.5 32.5 11 20 10 50
PLF 06-G01 6 G 1/8 24 29.5 9 14 10 50
PLF 06-G02 6 G 1/4 24 32 10 17 10 50
PLF 06-G03 6 G 3/8 25 33.5 11 20 10 50
PLF 06-G04 6 G 1/2 25 36.5 14 24 10 50
PLF 08-G01 8 G 1/8 29.5 33 8 14 10 50
PLF 08-G02 8 G 1/4 29.5 35.5 11 17 10 50
PLF 08-G03 8 G 3/8 29.5 37 11 20 10 50
PLF 08-G04 8 G 1/2 29.5 40 14 24 5 25
PLF 10-G01 10 G 1/8 36 36 8 174 10 50
PLF 10-G02 10 G 1/4 36 41 11 174 10 50
PLF 10-G03 10 G 3/8 36 43 12 20 5 25
PLF 10-G04 10 G 1/2 36 46 14 24 5 20
PLF 12-G01 12 G 1/8 38.5 39 8 19 5 20
PLF 12-G02 12 G 1/4 38.5 44.5 10 19 5 20
PLF 12-G03 12 G 3/8 38.5 46 11 21 5 20
PLF 12-G04 12 G 1/2 38.5 49 14 24 5 20

ㆍOne-Touch push-to-connect configuration allows for an instant tubing connection
ㆍImmediate strong engineering plastic(POM) sleeve disconnection by pressing the sleeve and then simply removing tube from fitting
ㆍFittings are already equipped with Teflon-treatment or o-ring on the thread
ㆍNickel-plated brass body ensures anti-contamination properties for an extended product life
ㆍApplicable Fluid Type / Air (No other type of gas or liquid)
