Quick Coupler AC male series
Model :
AC-M
ㆍSHPI A-system quick coupler is extensively used in the U.S.A, Swiss, Belgium and Holland.
ㆍTwo touch type design for plug inserting.
ㆍTwo touch type design for plug inserting.
| Model Number | Application |
L
(mm)
|
A
(mm)
|
T
(Thread)
|
ØB
(mm)
|
| AC20M | 1/4" | 47.5 | 11 | 1/4 NPT | 8 |
| AC30M | 3/8" | 49 | 12.5 | 3/8 NPT | 11 |
| AC40M | 1/2" | 50.5 | 14 | 1/2 NPT | 14 |
ㆍTwo touch type
ㆍBrass material
ㆍMax. working pressure: 300 PSI
ㆍBrass material
ㆍMax. working pressure: 300 PSI
ㆍPneumatic tools
ㆍAir piping
ㆍAir pressure equipment
ㆍAir piping
ㆍAir pressure equipment
