Quick Coupler NLC hose barb series
Model :
NLC-H
ㆍFor Japanese market, Asia, Russia, India, Brazil, New Zealand and Australia all use considerable quantities of this system.
ㆍA.K.A. :
Air Quick Coupler / Quick Disconnect Coupling
Quick Disconnector / Quick Connect
Air Quick Coupling / Air Connectors & fitting
Quick coupling / Pneumatic couplings
ㆍA.K.A. :
Air Quick Coupler / Quick Disconnect Coupling
Quick Disconnector / Quick Connect
Air Quick Coupling / Air Connectors & fitting
Quick coupling / Pneumatic couplings
| Model Number | Application |
L
(mm)
|
A
(mm)
|
ØT
(mm)
|
ØB
(mm)
|
| NLC400H | 1/2" | 85 | 37.5 | 1/2 PT | 9 |
| NLC600H | 3/4 | 89 | 41.5 | 3/4 PT | 13 |
| NLC800H | 1 | 92.5 | 45 | 1" PT | 19 |
ㆍFor massive flow
ㆍSteel material with plated finish
ㆍMax. working pressure: 300 PSI
ㆍSteel material with plated finish
ㆍMax. working pressure: 300 PSI
ㆍPneumatic tools
ㆍAir hose/ tube
ㆍAir pressure equipment
ㆍAir hose/ tube
ㆍAir pressure equipment
