• F.R.L GLS 200 Series Lubricator

F.R.L GLS 200 Series Lubricator

Model : GLS-200

ㆍThe structure of oil dripping adopts gap seal type, which makes the adjustment of oil supply more reliable.

ㆍAdjustable ring for oil supply can only revolve for one circle. The quantity of oil supply basically takes on linear distribution.

ㆍThe quantity of oil supply can be generally calculated according to the position of graduation ring.

ㆍSpecial drip nozzle structure will produce negative pressure in oil dripping outlet and the mist flow is minimal.

ㆍIt is available to add oil under pressure, and the oil bowl is large.

ㆍThe bracket can be selected for installation.

Model Number Fluid Port Size Pressure Range Proof Pressure Temperature Recommended Lubricant Oil Bowl Capacity Weight
GLS 200-06 Air 1/8" 1.5 - 9 Bar 15 Bar 5 - 60°C ISO VG 32 or equivalent 25cc 130g
GLS 200-08 Air 1/4" 1.5 - 9 Bar 15 Bar 5 - 60°C ISO VG 32 or equivalent 25cc 130g

Item / Model GLS 200
Oil Bowl PC
Body Aluminum Alloy
Distance Block TPU
Drip Pipe PC
Ejector Pin Brass
Indicating Ring POM
Adjusting Ring POM
Bowl PC
Sprayer Body POM
Sprayer Bottom Cap POM

ㆍUse pneumatic tools and equipment.

ㆍRequire clean air to be delivered to your facility or workplace.
