• One Touch Fitting PC male straight

One Touch Fitting PC male straight

Model : PC-compact

ㆍWorking Pressure Range / 0~150PSI /0~9.9Kgf/cm2(0~990KPa)
ㆍNegative Pressure /-29.5in Hg/-750mmHg(-750Torr)
ㆍWorking Temperature Range / 32°F~140°F / 0~60°C

Model Number ØD
T
(Thread)
L A H (Hex) Q'ty per bag Q'ty per box
PC 03M3C 3 M3*P0.5 16 3 8 10 100
PC 03M5C 3 M3*P0.8 16 4 8 10 100
PC 03M6C 3 M6*P.10 16 4 8 10 100
PC 0301C 3 PT 1/8 16 8 10 10 100
PC 04M3C 4 M3*P0.5 17.5 3 8 10 100
PC 04M5C 4 M3*P0.8 17.5 4 8 10 100
PC 04M6C 4 M6*P.10 17.5 4 8 10 100
PC 0401C 4 PT 1/8 17.5 8 10 10 100
PC 06M5C 6 M3*P0.8 17.5 4 10 10 100
PC 06M6C 6 M6*P.10 17.5 4 10 10 100
PC 0601C 6 PT 1/8 18.5 8 10 10 100

ㆍOne-Touch push-to-connect configuration allows for an instant tubing connection
ㆍImmediate strong engineering plastic(POM) sleeve disconnection by pressing the sleeve and then simply removing tube from fitting
ㆍFittings are already equipped with Teflon-treatment or o-ring on the thread
ㆍNickel-plated brass body ensures anti-contamination properties for an extended product life

ㆍApplicable Fluid Type / Air (No other type of gas or liquid)
