• One Touch Fitting PMM bulkhead union

One Touch Fitting PMM bulkhead union

Model : PMM-compact

ㆍWorking Pressure Range / 0~150PSI /0~9.9Kgf/cm2(0~990KPa)
ㆍNegative Pressure /-29.5in Hg/-750mmHg(-750Torr)
ㆍWorking Temperature Range / 32°F~140°F / 0~60°C

Model Number ØD T L Q'ty per bag Q'ty per box
PMM 03C 3 3 M8*P0.75 10 100
PMM 04C 4 4 M10*P1.0 10 100
PMM 06C 6 6 M12*P1.0 10 100

ㆍOne-Touch push-to-connect configuration allows for an instant tubing connection
ㆍImmediate strong engineering plastic(POM) sleeve disconnection by pressing the sleeve and then simply removing tube from fitting
ㆍFittings are already equipped with Teflon-treatment or o-ring on the thread
ㆍNickel-plated brass body ensures anti-contamination properties for an extended product life
ㆍApplicable Fluid Type / Air (No other type of gas or liquid)
