Compact One Touch Fitting PCF female straight
Model :
PCF-compact
ㆍWorking Pressure Range / 0~150PSI /0~9.9Kgf/cm2(0~990KPa)
ㆍNegative Pressure /-29.5in Hg/-750mmHg(-750Torr)
ㆍWorking Temperature Range / 32°F~140°F / 0~60°C
ㆍNegative Pressure /-29.5in Hg/-750mmHg(-750Torr)
ㆍWorking Temperature Range / 32°F~140°F / 0~60°C
| Model Number | ØD |
T
(Thread)
|
L | A | H (Hex) | Q'ty per bag | Q'ty per box |
| PCF 03M3C | 3 | M3*P0.5 | 15.5 | 3 | 8 | 10 | 100 |
| PCF 03M5C | 3 | M3*P0.8 | 17.5 | 5 | 8 | 10 | 100 |
| PCF 03M6C | 3 | M6*P.10 | 17.5 | 5 | 8 | 10 | 100 |
| PCF 04M3C | 4 | M3*P0.5 | 17.5 | 3 | 8 | 10 | 100 |
| PCF 04M5C | 4 | M3*P0.8 | 19 | 5 | 8 | 10 | 100 |
| PCF 04M6C | 4 | M6*P.10 | 19 | 5 | 8 | 10 | 100 |
| PCF 0401C | 4 | PT 1/8 | 22 | 7.5 | 12 | 10 | 100 |
| PCF 06M5C | 6 | M3*P0.8 | 19 | 5 | 10 | 10 | 100 |
| PCF 06M6C | 6 | M6*P.10 | 19 | 5 | 10 | 10 | 100 |
| PCF 0601C | 6 | PT 1/8 | 22 | 7.5 | 12 | 10 | 100 |
ㆍOne-Touch push-to-connect configuration allows for an instant tubing connection
ㆍImmediate strong engineering plastic(POM) sleeve disconnection by pressing the sleeve and then simply removing tube from fitting
ㆍFittings are already equipped with Teflon-treatment or o-ring on the thread
ㆍNickel-plated brass body ensures anti-contamination properties for an extended product life
ㆍImmediate strong engineering plastic(POM) sleeve disconnection by pressing the sleeve and then simply removing tube from fitting
ㆍFittings are already equipped with Teflon-treatment or o-ring on the thread
ㆍNickel-plated brass body ensures anti-contamination properties for an extended product life
ㆍApplicable Fluid Type / Air (No other type of gas or liquid)
