• One Touch Fitting POC round male straight

One Touch Fitting POC round male straight

Model : POC-mm

ㆍWorking Pressure Range / 0~150PSI /0~9.9Kgf/cm2(0~990KPa)
ㆍNegative Pressure /-29.5in Hg/-750mmHg(-750Torr)
ㆍWorking Temperature Range / 32°F~140°F / 0~60°C

Model Number ØD
T
(Thread)
L
(mm)
A
(mm)
H (Hex)
(mm)
Q'ty per bag Q'ty per box
POC 04-01 4 PT 1/8 20.25 8 3 10 100
POC 04-02 4 PT 1/4 19 10 3 10 100
POC 04-03 4 PT 3/8 19.5 11 3 10 100
POC 04-M5 4 M5*P0.8 20.5 3.5 2 10 100
POC 04-M6 4 M6*P1.0 20.9 4 2 10 100
POC 06-01 6 PT 1/8 21 8 4 10 100
POC 06-02 6 PT 1/4 23 10 4 10 100
POC 06-03 6 PT 3/8 20.7 11 4 10 100
POC 06-04 6 PT 1/2 24.7 14 4 10 50
POC 06-M5 6 M5*P0.8 21 3.5 2 10 100
POC 06-M6 6 M6*P1.0 21 4 2 10 100
POC 08-01 8 PT 1/8 25.7 8 5 10 100
POC 08-02 8 PT 1/4 25 10 5 10 100
POC 08-03 8 PT 3/8 22 11 5 10 100
POC 08-04 8 PT 1/2 226 14 5 10 50
POC 10-01 10 PT 1/8 30 8 5 10 100
POC 10-02 10 PT 1/4 31.5 10 6 10 100
POC 10-03 10 PT 3/8 29 11 8 10 50
POC 10-04 10 PT 1/2 26.7 14 8 10 50
POC 12-01 12 PT 1/8 30.6 8 5 10 50
POC 12-02 12 PT 1/4 33 10 6 10 50
POC 12-03 12 PT 3/8 30.6 11 8 10 50
POC 12-04 12 PT 1/2 32.8 14 8 10 50
POC 16-03 16 PT 3/8 36.7 11 8 5 25
POC 16-04 16 PT 1/2 36.7 14 10 5 25

ㆍOne-Touch push-to-connect configuration allows for an instant tubing connection
ㆍImmediate strong engineering plastic(POM) sleeve disconnection by pressing the sleeve and then simply removing tube from fitting
ㆍFittings are already equipped with Teflon-treatment or o-ring on the thread
ㆍNickel-plated brass body ensures anti-contamination properties for an extended product life
ㆍApplicable Fluid Type / Air (No other type of gas or liquid)
