Check Valve - CVPU
Model :
CVPU
ㆍWorking Pressure Range / 0~150PSI /0~9.9Kgf/cm2(0~990KPa)
ㆍNegative Pressure /-29.5in Hg/-750mmHg(-750Torr)
ㆍWorking Temperature Range / 32°F~140°F / 0~60°C
ㆍNegative Pressure /-29.5in Hg/-750mmHg(-750Torr)
ㆍWorking Temperature Range / 32°F~140°F / 0~60°C
| Model Number | ØD | L | Q'ty per bag | Q'ty per box |
| CVPU 04 | 4 | 44.5 | 10 | 100 |
| CVPU 06 | 6 | 47.5 | 10 | 50 |
| CVPU 08 | 8 | 54 | 10 | 50 |
| CVPU 10 | 10 | 63.5 | 5 | 25 |
| CVPU 12 | 12 | 65 | 5 | 25 |
ㆍSuitable for low pressure applications
ㆍThis valve allows compressed air from one side to flow and blocks the inverse flow to protect and maintain the vacuum line
ㆍEasily applied to low pressure piping
ㆍThis valve allows compressed air from one side to flow and blocks the inverse flow to protect and maintain the vacuum line
ㆍEasily applied to low pressure piping
ㆍApplicable Fluid Type / Air (No other type of gas or liquid)
