Hypretex Hydraulic Hose series SAE 100R7 Twin- Line Non-Conductive

Model : SR72N

ㆍInner Tube: Polyester elastomer

ㆍReinforcement: One or Two braided of synthetic fiber

ㆍCover: Orange high abrasion resistant polyurethane non-pinpricked cover

ㆍTemperature Range: -40°C ~93°C (-40°F ~200°F) for air and water based fluids

Part Number Size Code
Tube I.D
(inch)
Tube O.D
(inch)
Max. Working Pressure
(psi)
Min. Bursting Pressure
(psi)
Min. Bend Radius
(inch)
Weight
(lbs/ft)
SR72N-316 -3 3/16 0.39 3000 12000 0.98 0.04
SR72N-14 -4 1/4 0.484 2750 11000 1.38 0.064
SR72N-516 -5 5/16 0.555 2500 10000 1.77 0.08
SR72N-38 -6 3/8 0.63 2250 9000 2.17 0.097
SR72N-12 -8 1/2 0.799 2000 8000 2.95 0.133

ㆍMeets or exceeds SAE 100R7 standards

ㆍIdeal for general hydraulic services

ㆍLight weight and flexible

ㆍFor hydraulic oil and lubrication lines

ㆍFor medium pressure hydraulic

ㆍHigh voltage equipment

ㆍSafety and rescue equipment

ㆍAerial platforms

ㆍCranes -equipment requiring electrical high insulation
