One Touch Fitting PZA union cross
Model :
PZA-mm
ㆍWorking Pressure Range / 0~150PSI /0~9.9Kgf/cm2(0~990KPa)
ㆍNegative Pressure /-29.5in Hg/-750mmHg(-750Torr)
ㆍWorking Temperature Range / 32°F~140°F / 0~60°C
ㆍNegative Pressure /-29.5in Hg/-750mmHg(-750Torr)
ㆍWorking Temperature Range / 32°F~140°F / 0~60°C
| Model Number | ØD | M1 | M2 | E | C | Q'ty per bag | Q'ty per box |
| PZA 04 | 4 | 7.4 | 14.8 | 36.5 | 3.2 | 10 | 50 |
| PZA 06 | 6 | 7.9 | 15.8 | 38 | 3.2 | 10 | 50 |
| PZA 08 | 8 | 9 | 18 | 44.8 | 3.2 | 5 | 25 |
| PZA 10 | 10 | 11.8 | 23.5 | 56.8 | 4.2 | 5 | 20 |
| PZA 12 | 12 | 13.3 | 26.6 | 58.6 | 4.2 | 5 | 15 |
ㆍOne-Touch push-to-connect configuration allows for an instant tubing connection
ㆍImmediate strong engineering plastic(POM) sleeve disconnection by pressing the sleeve and then simply removing tube from fitting
ㆍFittings are already equipped with Teflon-treatment or o-ring on the thread
ㆍNickel-plated brass body ensures anti-contamination properties for an extended product life
ㆍImmediate strong engineering plastic(POM) sleeve disconnection by pressing the sleeve and then simply removing tube from fitting
ㆍFittings are already equipped with Teflon-treatment or o-ring on the thread
ㆍNickel-plated brass body ensures anti-contamination properties for an extended product life
ㆍApplicable Fluid Type / Air (No other type of gas or liquid)
