DOT Push-in Fitting Male Elbow 69 Series
Model :
DOT-69
ㆍWorking pressure: up to 150 psi
ㆍWorking temperature range:-40°F to +200°F
ㆍThreads: NPTF Standard. For other threads standards consult factory
ㆍWorking temperature range:-40°F to +200°F
ㆍThreads: NPTF Standard. For other threads standards consult factory
Model Number | Tube O.D | Pipe Thread NPTF |
35-6953202 | 5/32" | 1/8" |
35-690302 | 3/16" | 1/8" |
35-690304 | 3/16" | 1/4" |
35-690402 | 1/4" | 1/8" |
35-690404 | 1/4" | 1/4" |
35-690406 | 1/4" | 3/8" |
35-690602 | 3/8" | 1/8" |
35-690604 | 3/8" | 1/4" |
35-690606 | 3/8" | 3/8" |
35-690608 | 3/8" | 1/2" |
35-690804 | 1/2" | 1/4" |
35-690806 | 1/2" | 3/8" |
35-690808 | 1/2" | 1/2" |
35-691006 | 5/8" | 3/8" |
35-691008 | 5/8" | 1/2" |
35-691208 | 3/4" | 1/2" |
ㆍSHPI's D.O.T. Air brake fittings manufacturing meets D.O.T. FMVSS 571.106
ㆍAir brake specifications and SAE J2494 standards.
ㆍMachined from C3600/C3700 brass alloy
ㆍPre-applied thread sealant on all male pipe threads
ㆍOne-touch connection reduces installation time and cost
ㆍVarious shapes and configurations to meet vehicle applications and make installation easier
ㆍAir brake specifications and SAE J2494 standards.
ㆍMachined from C3600/C3700 brass alloy
ㆍPre-applied thread sealant on all male pipe threads
ㆍOne-touch connection reduces installation time and cost
ㆍVarious shapes and configurations to meet vehicle applications and make installation easier
ㆍRecommended Tubing: SAE J844 nonmetallic air brake systems
