DOT Push-in Fitting Tube Union M62 Series
Model :
DOT-M62
ㆍWorking pressure: up to 150 psi
ㆍWorking temperature range:-40°F to +200°F
ㆍThreads: NPTF Standard. For other threads standards consult factory
ㆍWorking temperature range:-40°F to +200°F
ㆍThreads: NPTF Standard. For other threads standards consult factory
| Model Number | Tube O.D |
| 35-M6204 | 4 mm |
| 35-M6206 | 6 mm |
| 35-M6208 | 8 mm |
| 35-M6209 | 9 mm |
| 35-M6210 | 10 mm |
| 35-M6211 | 11 mm |
| 35-M6212 | 12 mm |
| 35-M6215 | 15 mm |
| 35-M6216 | 16 mm |
ㆍSHPI's D.O.T. Air brake fittings manufacturing meets D.O.T. FMVSS 571.106
ㆍAir brake specifications and SAE J2494 standards.
ㆍMachined from C3600/C3700 brass alloy
ㆍPre-applied thread sealant on all male pipe threads
ㆍOne-touch connection reduces installation time and cost
ㆍVarious shapes and configurations to meet vehicle applications and make installation easier
ㆍAir brake specifications and SAE J2494 standards.
ㆍMachined from C3600/C3700 brass alloy
ㆍPre-applied thread sealant on all male pipe threads
ㆍOne-touch connection reduces installation time and cost
ㆍVarious shapes and configurations to meet vehicle applications and make installation easier
ㆍRecommended Tubing: SAE J844 nonmetallic air brake systems
