• F.R.L GFRS 600 Series Filter & Regulator

F.R.L GFRS 600 Series Filter & Regulator

Model : GFRS-600

ㆍEmbedded square pressure gauge is used to save installation space.(External circular pressure gauge is also optional.)

ㆍThe pressed-in self-locking mechanism can prevent the abnormal movement of the set pressure caused by external interfere.

ㆍBalanced design is adopted for the pressure adjustment mechanism.

ㆍIn addition to standard type, lower pressure type is optional.(The highest adjustable pressure 0.4MPa)

ㆍUnique diversion structure makes air flowing through properly rotate, which can more effectively separate the liquid from gas and reliably filter the solid grain.

ㆍThe filtering grade includes 5 um and 40 um (optional).

ㆍThree drain types are available: manual drain, semi-auto drain and automatic drain.

ㆍThe bracket can be selected for installation.

Model Number Fluid Port Size Filtering Grade Pressure Range Max Pressure Proof Pressure Temperature Drain Bowl Capacity Weight
GFRS 600-20 Air 3/4" 40µ, 5µ 1.5 - 9 Bar 10 Bar 15 Bar 5 - 60°C 230cc 3240g
GFRS 600-25 Air 1" 40µ, 5µ 1.5 - 9 Bar 10 Bar 15 Bar 5 - 60°C 230cc 3240g

Item / Model GFRS 600
Body Aluminum Alloy
Umbrella Baffle POM
Air Guider POM
Filter Element 40µ: Tin Copper ; 5µ: Fiber
Drain Bowl Aluminum Alloy
Leak Post POM
Pressure Knob POM
Adjusting Seat Aluminum Alloy
Adjusting Spindle HPB59-1
Diaphragm SUS304 covered with rubber
Pressure Spring Stainless Steel
Spring Stainless Steel
Bowl Guard Aluminum Alloy

ㆍUse pneumatic tools and equipment.

ㆍRequire clean air to be delivered to your facility or workplace.
