Quick Plug 30MOC male series

Model : 30MOC-M

ㆍM-system quick coupler is extensively used in the US market and other areas (Middle East, France, Spain and South America).
ㆍM-system quick coupler includes traditional two touch type and push-in one touch type.
ㆍPush-in one touch type couplers are available for 1/4" ,3/8" and 1/2" body for different flow requirements.


Model Number Application
L
(mm)
A
(mm)
T
(Thread)
ØB
(mm)
30MOC20M 1/4" 61.7 13 1/4 NPT 8
30MOC30M 3/8" 63.2 14.5 3/8 NPT 11

ㆍOne touch type
ㆍ3/8" body
ㆍBrass material
ㆍMax. working pressure: 300 PSI

ㆍPneumatic tools
ㆍAir hose/ tube
ㆍAir pressure equipment
