Quick Plug TP hose barb series
Model :
TP-H
ㆍSHPI T-system quick coupler is extensively used in the U.S.A and Australia.
| Model Number | Application |
L
(mm)
|
ØH
(mm)
|
A
(mm)
|
ØT
(mm)
|
ØB
(mm)
|
| TP20H | 1/4" | 45.5 | 12 | 21 | 7 | 4 |
| TP25H | 5/16" | 45.5 | 12 | 21 | 9 | 5.7 |
| TP30H | 3/8" | 47.5 | 12 | 23 | 10.5 | 7 |
| TP40H | 1/2" | 52.5 | 15.5 | 28 | 13.5 | 9.5 |
ㆍBrass material
ㆍMax. working pressure: 300 PSI
ㆍPneumatic tools
ㆍAir piping
ㆍAir pressure equipment
