HR09 Series | Ultra-Compact Spring-Driven Hose Reel

Optimized for High-Density Assembly Lines & Workstation Efficiency

The SHPI HR09 Series is a specialized pneumatic solution engineered for automated assembly lines and fixed workstations. With its no-lock, continuous tension mechanism, the HR09 ensures instant air access and clutter-free hose management, maximizing productivity in fast-paced manufacturing environments.

Core Capabilities

• Ultra-Compact Footprint (Approx. 1 kg) The 13cm diameter design saves valuable workspace and allows for high-density installation on workbenches or equipment frames without adding structural load.
• Continuous Tension (No-Lock) Mechanism Eliminates operational delays by ensuring the hose retracts automatically and remains under constant tension. This prevents sagging or tangling during repetitive, fixed-station tasks.
• Rugged, Impact-Resistant ABS Casing Industrial-grade durability designed to withstand long-term production use, significantly reducing maintenance downtime and replacement costs.
• Versatile Suspension Mounting The hanging-style design supports rapid reconfiguration of production lines, allowing for quick adjustments to changing manufacturing processes and layouts.

Technical Specifications

• Ideal For: Automated Assembly, Fixed Workstations, Lean Manufacturing.
• Casing: Heavy-duty, Impact-resistant ABS.
• Mechanism: Continuous Tension (Automatic Retraction).
• Tubing: High-flexibility PU (Polyurethane).
• Quality Assurance: 100% Made in Taiwan.
